Marble Platform (Marble/Granite Material Optional, Including Ordinary Type, Precision Type, Marking Type)

Core Selling Points

• Ultra-High Flatness Precision: Precision grades cover 000/00/0/1, flatness error ≤0.002mm/m (Grade 000), compliant with GB/T 20428-2006 and JB/T 10027-2016 standards, providing stable reference surfaces for various precision operations
• High-Quality Natural Base Material: Made of high-density natural marble/granite, with hundreds of millions of years of natural aging treatment, complete release of internal stress, non-magnetic, non-conductive, Shore hardness ≥HS75, wear-resistant and corrosion-resistant, and the surface is not easy to scratch or deform
• Extreme Structural Stability: Low coefficient of thermal expansion (≤5.0×10^-6/℃), excellent thermal stability, can maintain high precision at room temperature and in environments with small temperature fluctuations, no creep or settlement after long-term use
• Precision Grinding Process: The working surface undergoes multiple refined processes such as rough grinding, precision grinding and polishing, surface finish up to Ra0.012μm, uniform flatness, close fit with the tested parts/tooling, and uniform load-bearing (unit area load-bearing ≤200kg/㎡)
• Multi-Scenario Adaptation: Supports various tabletop processing (smooth surface, T-slot, threaded hole, etc.), no oiling required for rust prevention, daily cleaning with a lint-free cloth is sufficient, suitable for long-term stable use in laboratories, precision workshops, metrological detection and other scenarios

Standard Size Specifications

Precision Grade Description

• Grade 000: Flatness error ≤0.002mm/m, suitable for national metrology laboratories, ultra-high precision detection benchmarks, and reference part calibration platforms
• Grade 00: Flatness error ≤0.003mm/m, suitable for aerospace precision manufacturing, supporting worktables for high-end CNC machine tools, and precision instrument detection platforms
• Grade 0: Flatness error ≤0.005mm/m, suitable for precision mechanical processing tooling positioning, large workpiece detection benchmarks, and electronic component precision processing platforms
• Grade 1: Flatness error ≤0.01mm/m, suitable for conventional mechanical manufacturing worktables, automated production line tooling platforms, and construction engineering detection reference surfaces

Application Fields

• Precision Machinery Manufacturing: Supporting worktables for CNC machine tools, precision grinder tooling positioning platforms, and mold processing and detection reference surfaces
• Aerospace Industry: Precision processing worktables for aircraft parts, detection platforms for aero-engine components, and assembly and positioning benchmarks for aerospace equipment
• Electronic Semiconductor Manufacturing: Semiconductor equipment worktables, precision detection platforms for electronic components, and processing and positioning reference surfaces for circuit boards
• High-End Automobile Manufacturing: Detection platforms for automobile engine blocks, precision processing tooling for transmission components, and detection benchmarks for new energy vehicle battery components
• Metrological Detection Field: Calibration platforms for laboratory metrological standards, flatness detection benchmarks for large workpieces, and calibration worktables for detection instruments
• Other High-End Fields: Worktables for medical device manufacturing, precision instrument assembly platforms, and special reference platforms for scientific research experiments

Customization Service

Custom sizes are available (tabletop size: minimum 200mm×150mm, maximum 4000mm×2000mm; thickness: minimum 40mm, maximum 300mm), and inch specifications (such as 12″×8″, 32″×24″, etc.) can be customized; personalized processing is supported, including T-slot specifications/quantity, threaded hole position/specifications, tabletop marking precision, chamfer size, etc. Precision grades and grinding processes can be adjusted as required.

Usage Notes

• Store in a dry, flat and vibration-free environment, avoid moisture, exposure to sunlight, rain and severe collision. It is recommended to support with a special wooden bracket or shockproof pad to ensure uniform force on the platform and prevent deformation under pressure; regularly check the cleanliness and flatness of the tabletop during long-term storage.
• Ensure the installation foundation is flat and firm during installation, adopt multi-point uniform support, use a level to calibrate the levelness of the platform, and ensure the flatness meets the usage requirements; after installation, let it stand for 24 hours before use to avoid precision fluctuations caused by immediate force.
• Before use, gently wipe the tabletop with a lint-free cloth dipped in neutral detergent to remove dust, oil and other impurities to ensure the reference surface is clean; avoid scratching or impacting the tabletop with hard objects. If there are stubborn stains, do not scrape them with sharp tools, and use special cleaning products to handle them.
• Handle with care when placing workpieces or tooling to avoid severe impact; control the load within the rated range to avoid local overloading leading to tabletop deformation or precision damage; lay a protective pad on the tabletop when moving large workpieces to reduce friction damage.
• Perform precision calibration regularly, it is recommended to calibrate every 6-12 months. Calibration shall be carried out by professional metrological institutions in accordance with relevant national standards; if abnormal tabletop precision, surface damage and other conditions are found during daily use, stop the machine in time for inspection and treatment.
